Design and Build a PCB - SMD LED Learn electronics engineering

i'm going to show you how to design and make your very own version of this circuit board it's perfect for learning electronics and you can even download my design files for free and order the circuit board yourself links down in the video description for that for the power supply i will use some standard 1. 5 volt batteries i will use this battery holder to combine them to create a 3 volt supply for the circuit board the multimeter shows slightly more than three volts as the batteries are new for the lights we have two main options the standard through-hole leds or smd type leds which stands for surface mount device we can see a standard led here and next to it is an smd led i'll zoom in so you can see it here you can see it next to a scale so you can really see just how tiny these components are however it can produce a good amount of light so i will use five of these as that will keep the circuit board simple but also fairly small the smd leds are tricky to handle so you'll need some tweezers for that my top tip is to handle them on a flat dark colored surface because if you drop them on a carpet you're probably never going to find them again as a quick test how many objects can you see in this carpet tell me the grid reference for them and let me know your answers in the comment section down below the smd led typically has a small dot on the top although you might need a microscope to see this but sometimes the manufacturer uses this to indicate the anode and other times it's used to indicate the cathode so always check with a manufacturer's data sheet or you can test it yourself here you can see that this led illuminates when the positive is connected to the dot on the back you should find a symbol also again this could be either the anode or the cathode so check the data sheet or test it here we can see the led illuminates when it's connected like this to find the led we're going to go to a suppliers website and search through their components i like these ones because they have a pcb footprint which we can use later in the design we can also see that this led has an orange light it has a forward current of 20 milliamps and a forward voltage of 1. 9 volts importantly the forward voltage is less than the 3 volt supply we're going to use that makes our circuit board design very easy so now we have two options we can connect the leds in series or parallel if we connect them in series then each led is going to remove an additional 1.

9 volts so that means we need around 9. 5 volts of power supply to the circuit board to be able to power them all so we can't use this method we will instead connect them in parallel so that each led receives the same voltage then we would only need a supply of 1. 9 volts however we will be using the 3 volt supply by the way we have covered series and parallel circuits in detail in our previous video links down below for that now if we provide an led with 3 volts and it's only rated to handle 1.

9 volts then we're going to destroy it too much current is going to flow through the component and it will burn out so we need a resistor to limit the current and remove that excess voltage what size resistor do we need well we have a 3 volt supply and the led has a voltage drop of 1. 9 volts so if we subtract this from the power supply then we have to reduce the voltage by 1. 1 volts the leds are rated for 20 milliamps or 0.

02 amps so 1. 1 volts divided by 0. 02 amps gives us a resistance of 55 ohms and by the way we have also covered ohm's law in detail previously links down below for that so we also need to know the power rating of the resistor we calculate that from the current of 0.

02 amps squared multiplied by 55 ohms which gives us 0. 022 watts and that is a very small amount which is a good thing because that's how much energy we're wasting as heat from the resistor to remove that excess 1. 1 volts we basically convert the energy into heat to remove it okay so we want to use smd components so we search the supplier website and i will use this one it is rated for 56 ohms so it's slightly higher than we need but close enough it has a tolerance of one percent meaning it could be anything between 55.
