Stock Price Prediction & Forecasting with LSTM Neural Networks in Python

Hey everyone my name is Greg Hogg and welcome to  my channel today we'll be forecasting Microsoft stock using LSTM neural networks this is a  very important project to put on your resume so i'd really highly recommend watching the video  in its entirety i made it as clear and concise as i possibly could so i really think you're going to  find this useful enjoy the video i'll see you in there. We first want to grab the dataset which  we can get from this Yahoo Finance link here which will bring us to Microsoft Corporation  stock page we can scroll down and change the time period from one year to max to get all of  the information and then click apply we want to download which will bring a csv to your computer  we need to bring that csv into our environment so in google collab we go here and then upload  the file we can simply rename it by deleting those extra characters and pressing enter so we  will do import pandas as pd and make df equal to dot read csv passing the file name of msft. csv  close that and then outputting df 9082 rows of stock information it goes all the way from  the beginning 1986 all the way till now today which is 2022 march 23rd if you're following  along you might see a different date here closer to your today notice that we don't trade  stocks every single day there's a gap here 19 and 20 don't exist and many other pieces in  the middle don't exist as well that is okay looking at the different columns of the data  set we have the date and on that date what the stock opened at the highest value for that day  the lowest value for that day what it closed at the adjusted closing value and then the volume  of stocks traded that day we're going to keep things simple by just using the closing value  so we'll have the date and what that value was at the end of that date we're going to discard the  other columns we can do that by doing df is equal to df and just the name of those two columns  which is date and then close we'll set that and then outputting df we should see only those  two different columns we currently have a problem with our date column as it's actually not a date  it's just a string that has the year then the month then the day we can see this if we type df  sub date we should see name of date except it's a d type of object we want that to be a date we  usually use this thing called date time so we will import date time and then make a function so we  will define a function called string to date time which is going to take a string s which will be  any of these strings here any string that looks like this we're going to pass that to the function  in s and it's going to return the associated date time for that string so in this function we'll  create a variable called split and set that equal to the s dot split the hyphen which is the  separator for each of these so a split is going to be the list of the year and then the month and  then the day we can extract those three pieces year month and day equal to the split of zero  split of one and split of two these objects are actually strings right now we want to make them  integers so we'll just wrap each of them in int so we can just return the datetime.

datetime  and then pass the year equal to our year the month equal to our month and the day equal  to our day we'll now test out our function by creating an object called date time underscore  object equal to the string to date time so calling our function and we'll pass the first day in  our data set which happens to be 1986-03-19 if we output this date time object we should see  that it outputs datetime. datetime of 1986 319 and this is for the time but we don't need any of that  now what we need to do is apply this function to everything in our date column because we have in  df this whole date column we want to make all of these date strings actual date objects so we'll  set df subdate equal to itself so df subdate dot apply so we're applying a function to that column  just the one that we made above we can pass string to date time into this function note that we're  not calling the function here we're passing the function itself to the supply function now if we  were to output our data frame column again df sub date should now show us the following it looks  like this is an error but this is just a warning this is okay it looks like our column is the same  as it was before but actually the d type is now date time 64. this is just what pandas converts  it to this is actually what we want our data frame is almost ready we just have one more step if you  look at df you can see that it's index this column right here is actually integers we want to replace  that column and make that date column the index we can do that very easily by setting df.

index equal  to the df. pop which means we take away the column and return it so df. pop passing the date and then  outputting df we'll see that it did exactly what we desired make that date column the index and  then we just have the closing value as a column now that we did that we can quickly plot our data  using matplotlib if we do import matpotlib.

pyplot as plt we can do a plt. plot of the df. index and  the df sub close what we can see is from 1986 all the way up until 2022 the stock goes  absolutely crazy after it hits about 2016 or so and then there's a little bit of a drop at the end  now because we're using the lstm model we need to convert this into a supervised learning problem  we're going to do this by making a new function we'll call it define df to windowed df it's going  to take the data frame which will just pass df it'll take a first date string and a last date  string and then a positive integer we'll set it equal to 3 by default this function is  also going to need numpy so we're going to import numpy as np now it turns out that  this code is extremely difficult to write so i'm going to just go in here and paste in  the code if you need to know what that code is make sure you go to the video description and  check out the tutorial and look at it there i also pasted in how to create this object called  window df which is calling this function with certain parameters i'll explain that very shortly  i just need to show you the result of window df window df is now a data frame where we have a  target date column a target minus 3 minus 2 minus 1 and then the target these are all the stock  closing values from before so this target date corresponds to that value here if we look above  at 3 18 it should be 0.

099 so 0 3 18 let's take it one more time for me to remember oh 3 18 is 0. 099  why don't we have this row that row and that row well that is all about what this windowed function  is so this window data frame is converting a date into getting its three previous values and then  what it actually was so if we go back again 0. 097 if we look at what .

097 is that is three  days before this is the target date this is three days before if we were to look at  target minus two this would be target minus two for that date and this is target minus 1 and this  is the target we have that for every single date that it allows for so of course we couldn't have  dates previous than this because we didn't have a whole three values before it this was the first  date that we could start with hence we actually called that as the starting date there as the  last date that's the last one we wanted which is right here the three previous and then its target  value right there the reason i started calling it target is to think about this column as the  output because that's what our machine learning model needs we have what led up to it so three  days before two days before one day before what is our corresponding output because this is the  input that's fed into the model and this is the corresponding output it's just like a regression  problem or any other supervised learning problem you have an input and then you have an output you  have another input you have another output this is just the whole data frame which displays the  inputs the outputs and the corresponding date for that output so that was really how we converted  this problem to a supervised learning problem we set up its output date with that output and  its corresponding input for that row now we just need to convert this into numpy arrays so that we  can feed it directly into a tensorflow model so to do that we're going to create a function we're  going to call it windowed df so it takes a window df like above and converts it to date x y okay so  this is actually three things we're going to get a list of dates we're going to get an input matrix  x actually it's going to be a three-dimensional tensor we'll see shortly and y is going to be the  output vector so x is going to be this matrix here except it's actually going to be three-dimensional  y is going to be this output vector here and dates we want to keep those so dates is going to be  this column here this function is just going to take one parameter called window data frame first  is going to do df as numpy it's going to convert the whole data frame into a numpy array we do that  with windowed data frame dot 2 underscore numpy bracket bracket to get the dates it's very easy  we just set dates equal to df underscore as numpy and then we need to get all of the rows so we put  a colon and then we put 0 to say just the first column because it's this column right here getting  the input matrix is a little bit more confusing so we're going to call it first middle matrix not our  final input matrix middle matrix is equal to df underscore as numpy and again we want all the rows  so we'll put a colon but we only want to start at the first column because we don't want that date  column and then we want to go up until but not include the last one so 1 until negative 1 says  all of these rows here that's what the colon does and then 1 to negative 1 says just this piece of  information in the middle so all of this piece now unfortunately what you'll find if you go through  like that is that it's actually the wrong shape for the lstm we need x is equal to middle matrix  but then we need to do a reshape so we'll do a reshape where the first dimension is the length  of dates so this is the number of observations that's pretty common for any tensorflow model but  now we need the second piece of this shape to be middle matrix dot shape sub 1. that's just  however many columns we had and it would be the same as that n our window value i'm just  making it this because we have access to that the last piece just has to be a 1 here because we  are technically only using one variable we have three different values of that variable and how  it changes over time but we're still only doing what we call univariate forecasting because we're  just looking at how the closing value changes over time if instead we had used some of those values  at the very beginning like the open the high the volume and those variables well then we'd have  to put a different number down here we'd have to put two or three or four as this number we're  just doing one because we're doing univariate forecasting now luckily from here this function  is very easy we can just get our output vector y is equal to df as numpy where again we want  all of the rows but we only want the last column that we can just do return three things dates x  and y there's just a minor difficulty if you go on later you'll see that has an error that we  can fix with dot as type float 32 actually np dot float32 if we change those for x and you  also do that for y y dot as type numpy. float32 you'll fix a weird error you'll find later now  to call this function we again want those three things we'll get dates x and y and set that equal  to windowed df to date x y just our function there and we'll pass in our window df from before these  three things should be numpy arrays so we will get dates.

shape x dot shape and y dot shape and see  that we have 9079 of each of these three things our input matrix and then three by one because  we're looking three steps in the past but for only one type of variable now we're going to split the  data into train validation and testing partitions the training will train the model the validation  will help train the model and then the testing is what we're going to use to really evaluate the  performance of the model we need two integers to help with the split we'll get q80 first that's  going to be the integer of the length of dates times 0. 8 then we'll get q90 which is equal  to the int of the length of dates times 0. 9 so we'll make the training partition the first  80 percent so we'll get dates train x train and y train each of those are going to be each of  their pieces so this will be dates but then only up until q80 to make it the first 80 percent  we'll do the same thing with x so x up until q80 and then y up until q80 because it's a little bit  slow i'm just going to paste in these two lines to get vowel and test which we can get val dates  val x file and y about by going dates q 80 to q 90 then x q a to q 90 and y q to q82 q90 that's  all that information between the 80 and 90 pieces then we just get the testing information by  saying q90 onward to get that last 10 so you can see it's ordered the first training piece is up  until the first eighty percent the validation is the eighty to ninety percent ten percent and then  the test is that final ten percent from the ninety onward we can visualize and color this very well  with matplotlib so we'll do plt.

plot then we're going to get dates train and then y train we'll do  the same so plt. plot for val so dates underscore val and y val finally the same for test plt. plot  dates test and y test and we'll just add in a legend so that you can see which is which although  it should be pretty obvious plt.

legend train then validation then test if you plot that you're going  to see that train is all this information here marked by the blue then validation is this piece  and then test is this piece here it's time to create and train our model we can do a few imports  from tensorflow from tensorflow. comstep models get sequential we're going to build a sequential  model from tensorflow. curious.

optimizers we'll get atom that's the optimizer we're going to  use and then from tensorflow. kira's import layers we'll make a model that is sequential and built up  of many layers so we'll define our model and we're going to call it model is equal to a sequential  and then we'll pass that a list of layers so the first one is just the input layers dot input  and we need to specify the shape of the input remember we don't need to specify the batch number  or how many examples three by one again it's three because we're doing three days in the past and  that's one because we need only one feature only univariate forecasting now that we've specified  the input layer we're ready to do an lstm layer so we will do layers dot lstm and capitals and this  number is relatively arbitrary but we will choose 64 which is a relatively big but not super big  number of neurons for the lstm all that you really need to know about this number is the bigger  the number the more complicated the model is the more prone it is to overfitting and the more  heavy duty it is considered we will add instead of an lstm a dense layer layers. dense will choose  32 for a similar reason as above you're also very welcome to stack dense layers and so we'll just  actually paste that in again and have another 32.

we're not going to mess with the activation  functions for the lstm but for the dents it's usually a good idea to set activation equal to  relu so we will do that for both of those dense layers now we must specify the output of our model  and since we are only forecasting one variable we're just trying to predict say the next value  we only want this to be a layers dot dense of one where we don't change the activation function as  by default it's linear which is desired we can now close this up and specify that the model is going  to be compiled to compile the model we must set the loss function and the loss function we want  to minimize is the mean squared error so we will just write the string of mse for mean squared  error we also need to specify the optimizer so we will set the optimizer equal to the atom  optimizer where we specify that the learning rate is equal to for this example it turns out that  0. 001 is going to work out pretty well if you're doing a different problem the learning rate is  something you definitely want to play around with as well as these values here we also want to  specify a new metric is going to be metrics equals we need to put it in a list it's the mean absolute  error this number tells us on average how much we're off by rather than the squared distance we'd  rather look at this although we need to minimize the mse as this is not differentiable we're now  ready to fit the model so we can do model dot fit we pass our inputs of x train and y train  and then we specify that the validation data is equal to the tuple of x val and y val  we're going to let this run for 100 epochs which means 100 runs through the data set i'm  going to press enter and we can see what happens as we can see at this point it looks  like it's not really changed very much so we can actually cancel this and it is going  to save whatever progress it's done so far now to briefly analyze this we mostly care about  the validation mean absolute error going down we can see it's at 14 at the beginning then it  goes to 11 10 9 and then it hovers around 8 9 10 and that's when i was ready to stop it  because it wasn't really changing all that much it's much easier to visualize what's going on  instead with graphs so before worrying about the code i'm just going to show you the pretty picture  we can make for it predicting on the training set so the orange is the actual observed observations  it's what really happened from 1986 to 2016. the blue is what we predicted so each time it got the  three previous and it tried to predict the next one that's also what it was trained on to make  that run we simply get the training predictions with model.

predict on x train and then we have to  do a flatten then we can do a plot of dates train and the train predictions and dates train and  y train that's that blue and the orange curve and then we just create the legend since i  explained that code for the train i feel no real need to explain it much for the validation as this  is literally the same thing but replacing the word train with val so for the validation we get this  graph or it follows it until you know about 2017 and then it just really flattens off which is  the same time when it actually starts to pick up so the observations what really happened is it  went up like this but the predictions it actually just started to zone off and it couldn't follow  it anymore if we were to look at the test this is again just replacing that word train with test  this picture is even worse it doesn't follow it at all it actually thinks it's going down a little  bit whereas it's going up a lot and then it goes down i'm now going to put all three of those  pictures on the same graph again the code is not hard it's just annoying where we first plot  the training predictions and the observations the validation predictions and the observations  same for the test and then we create the legend we see that this picture again for the training  it follows it very closely and for the red piece is what actually happened in validation the green  is what it thought happened not good at all the brown is what really happened and the purple is  what it thought for the test really really bad at that point it turns out that these lstm models  are very bad at what we call extrapolating and so if it was trained on data only in this range here  only up until like the 50 value it's not going to be good at predicting stuff this high even though  it is given say his input these three values here and has no idea what to do with them because it's  not going to extrapolate well extrapolate means basically learn data outside its range a line  extrapolates well because if we drew a line here we could just continue drawing that line up like  that but if the lstm is only trained on this data here it will have no idea what to do when the  values are increasing and are this big another way to think about it is that all this information  here it might actually not be that helpful because over here the values are way up like this and the  pattern starts changing a lot so maybe we don't want to train it on all of this maybe we just  want to train it on say this information here and then validate over here so we'll do just that  we're going to pick some day over here to start training at we do need to know that this date is  actually in the data set and for that we'll go to our data set over here and select the time period  of one year and if we apply that we just need to scroll back all the way to the bottom and see that  one date that we know exists is march 25th 2021 we will use that as our starting value instead so  that means we need to change our windowed function above or not actually change the windowed  function itself but just change how we're calling it we need to change this value here to  be the year is going to be 2021 03 is fine and then 2 5 is a date we know exists as you can see  here i had this in a comment for me to remember so now the first date will be 2021 0325 and these  are its corresponding information the end date is exactly the same and we only have 252 rows  this time way less information we should have no problem just re-running the cells we already did  so we're going to do that which gets dates x and y note that they're smaller this time we'll again  split the data set and make sure that we plot it properly so our starting date up until about  the middle over here is train then validation then test and note that we've already seen values  in this range so it should be okay to predict values in the same range over here since we only  change the number of things the model is seeing the model is actually fine as is we can run  that again and it's going to run a lot faster now we'll see again that our mean absolute error  goes down pretty low and for the validation a lot better than it was before we can recreate  all of our graphs so to plot the training we can see here the train it doesn't follow it  quite as well as before but that's totally okay if we see here for the validation it got so  much better now look at how zoomed in this is these values are extremely close to each other and  if we were to do it for the test as well the tests are also extremely close to each other if we were  to plot them all on the same graph again we would see here zoomed out that they're all very close to  each other the predicted first the observation is very very close no matter whether it's the train  the validation or the test now the video could be done here but i want to show you how you could try  and predict long term because all of these values any of these predictions we're assuming we had the  actual three days before and that data was real then we used those three days before to make the  prediction and then the next day we would have the actual three and then we'd use that predict the  next day well what we're actually going to do is train here and then pretend that's all the  data that we have and let the model recursively predict the future and see what it has to say so  to make that function we're first going to do from copy import deep copy we'll make a list and start  to build this up called recursive predictions is equal to an empty list and then we'll get  recursive dates these are the dates on which we're predicting for this is already known and  this is equal to np dot concatenate the dates val and the test val this is because the dates we're  predicting are here onward so we're training on all of this in fact we've already trained on  all of that and then the recursive predictions are going to be for these following dates so  now we can loop through those dates for target date in the recursive dates we'll get our most  recent input so the last we'll call it window i'm just copying it so we don't change anything deep  copy of x train sub negative one because the last window that we actually had access to was the very  last three over here that is stored in x trains of negative one and we need to start predicting for  the future so we need to get our next prediction so the prediction for the next day that will be  equal to model. predict unfortunately we actually have to make it the numpy.
